Viscosity Grade Bitumen (VG)

Viscosity Grade Bitumen, commonly referred to as VG Bitumen, is classified based on its viscosity (resistance to flow) at specific temperatures, rather than its penetration value. It provides a more consistent performance classification, especially in varying climatic and traffic conditions. Viscosity testing is conducted under ASTM D2171 or similar global standards at 60°C and 135°C to determine the grade, ensuring predictable performance across all applications.

VG Bitumen is widely used in the construction of roads, highways, and industrial surfaces where performance under stress, temperature, and traffic is critical. It is especially preferred in regions where the penetration grade may not accurately predict pavement behavior under high loads or thermal stress.

Key Features & Benefits

Viscosity-Based Classification

Instead of penetration depth, VG Bitumen is classified by viscosity, measured in poise at 60°C and centistokes at 135°C. Common grades include VG10, VG20, VG30, and VG40. Lower VG numbers indicate lower viscosity and softer bitumen, suitable for colder climates, while higher numbers are for hotter climates and heavy traffic.

Standardized Grades

Viscosity grades follow specifications like IS 73:2013 (India) and are being adopted worldwide due to their reliable performance. Each grade has set minimum viscosity and softening point values to ensure stability and strength in diverse environments.

Wide Application Range

VG Bitumen is used in hot mix asphalt for road construction, surface dressing, and industrial paving. VG10 is ideal for spraying and cooler areas, VG20 for standard paving, VG30 for highways, and VG40 for heavy-duty traffic zones and hot regions.

Consistent and Reliable Performance

Because viscosity is less temperature-sensitive than penetration, VG Bitumen offers more reliable results in real-world conditions. It improves load-bearing capacity, reduces deformation risk, and enhances fatigue resistance in pavement layers.

High Quality and Proven Efficiency

VG Bitumen ensures a long service life of roads and infrastructure, combining quality with cost-effectiveness. It’s widely trusted in both national and international road projects for its durability and structural integrity.

Best Quality
Bitumen

Affordable Cost

Quality. Cost. Trust.

Safety Measures During Handling and Transport

Storage Safety: Always store VG Bitumen in tightly sealed, temperature-controlled containers to avoid overheating and reduce fire risk.

Proper Labeling and PPE Use: All containers must be clearly labeled. Workers should wear PPE including gloves, goggles, and flame-resistant clothing while handling hot bitumen.

Transport Guidelines: Vehicles must follow safety regulations with proper spill containment. Bitumen must be accompanied by a Material Safety Data Sheet (MSDS).

Insurance and Contingency Planning: Ensure logistic coverage and a well-prepared emergency response plan for spills, accidents, or leaks.

Fire Prevention: Store bitumen away from ignition sources. VG Bitumen has a high flashpoint (typically above 230°C), making it relatively safe under controlled conditions.
